Material
Guide rail tool steel 1.2842.
End pieces 1.0531.
End pieces 1.0531.
Version
Guide rails hardened (60-62 HRC) and ground.
End piece black oxidised.
End piece black oxidised.
Show more
Show less
Description
Material
Guide rail tool steel 1.2842.
End pieces 1.0531.
End pieces 1.0531.
Version
Guide rails hardened (60-62 HRC) and ground.
End piece black oxidised.
End piece black oxidised.
Note
See 21052 for the matching roller cage.
The guide rails are installed in precision slides (21034, 21035, 21038 and 21040). They can therefore also be used as spare parts.
Supplied as single guide rails without roller cages. Order additional guide rails and roller cages separately
The guide rails are installed in precision slides (21034, 21035, 21038 and 21040). They can therefore also be used as spare parts.
Supplied as single guide rails without roller cages. Order additional guide rails and roller cages separately
Drawing reference
1) end part
2) without roller cage (21052)
2) without roller cage (21052)
