{"product":{"productId":"agid.31971","price":105.2,"name":"Linear housing units quadro, closed"},"currency":"EUR"}
Material
Housing aluminium
Version
Housing bright.
Show more
Show less
Description
Material
Housing aluminium
Version
Housing bright.
Note
Ready to install linear housing units consisting of an extruded aluminium housing with four self-aligning linear ball bearings 21510 and seals both sides. The bearings are secured in the housing with DIN 472 circlips.
Recommended shaft tolerance: h6.
Load ratings according to the linear ball bearing specifications (x4).
Recommended shaft tolerance: h6.
Load ratings according to the linear ball bearing specifications (x4).
On request
Linear housing units can be equipped with any of our linear ball bearings.
Drawing reference
1) centring hole
Accessory
End seals 21560.
Precision guide shafts 21595.
Fastening screws 07160 or 07161.
Precision guide shafts 21595.
Fastening screws 07160 or 07161.
